Coil Tie

Description

The Dayton Superior B1 Two-Strut Coil Tie and B2 Four-Strut Coil Tie, when used as inserts for lifting and handling thin wall precast elements, are extremely effective.

FEATURES & BENEFITS

• It can be used with or without cones
• Can be combined with coil rod to form an adjustable tie
• Safe working load provides a factor of safety of approximately 2 to 1
• The coil threads are fast acting and self-cleaning.

Product Data

Available in 1/2”, & 3/4” diameters

To determine the required coil tie length, subtract two times the desired or specified setback from the wall thickness

Safe working load provides a factor of safety of approximately 2 to 1

Coil ties are available with an optional Screw-on Coil for use with the B30 Screw-on Plastic Cone to set the insert back from the face of the concrete. Minimum spacing between inserts is twice the corner distance.
